LH79524/LH79525 User’s Guide I/O Configuration
Version 1.0 11-35
5:4 PE4
PE4/LCDSPLEN/LCDREV Assignment
00 = PE4
01 = LCDSPLEN
10 = LCDREV
11 = Reserved
3:2 PE3
PE3/LCDCLS Assignment
00 = PE3
01 = LCDCLS
10 = Reserved
11 = Reserved
1:0 PL5
PL5/D29 Assignment (LH79524 Only)
00 = PL5
01 = D29
10 = Reserved
11 = Reserved
Table 11-49. MUXCTL19 Fields (Cont’d)
BIT NAME DESCRIPTION
