LH79524/LH79525 User’s Guide I/O Configuration

Version 1.0 11-51

5:4 PH4

Pin PH4/ETHERTX0 Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

3:2 PH3

Pin PH3/ETHERTXER Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

1:0 PH2

Pin PH2/ETHERRXCLK Resistor Assignment

00 = No Pull-Down or Pull-Up

01 = Pull-Down

10 = Pull-Up

11 = Reserved

Table 11-67. RESCTL23 Fields (Cont’d)

BIT NAME DESCRIPTION
