LH79524/LH79525 User’s Guide Timers
Version 1.0 15-9
11:10 CMP0
Output Value Select Timer/Counter Operation: Programs the value (when a
compare match occurs) output on CTCMP0A when the CNT0 Register matches
the T0CMP0 Register.
00 = No change occurs to the output CTCMP0A
01 = Output 0 to CTCMP0A
10 = Output 1 to CTCMP0A
11 = Toggle the output to CTCMP0A
PWM Operation:
00 = Invalid
01 = Active LOW PWM output polarity
10 = Active HIGH PWM output polarity
11 = Invalid
IMPORTANT: CMP1 and CMP0 must be programmed to the same polarity.
9:8 CAPE
Input Edge Select Selects the edge used as the capture trigger on the
CTCAP0E pin. This field and the capture function are inactive in PWM mode.
00 = Capture input CTCAP0E is ignored
01 = Rising edge of CTCAP0E
10 = Falling edge of CTCAP0E
11 = Both edges of CTCAP0E
7:6 CAPD
Input Edge Select Selects the edge used as the capture trigger on the
CTCAP0D pin. This field and the capture function are inactive in PWM mode.
00 = Capture input CTCAP0D is ignored
01 = Rising edge of CTCAP0D
10 = Falling edge of CTCAP0D
11 = Both edges of CTCAP0D
5:4 CAPC
Input Edge Select Selects the edge used as the capture trigger on the
CTCAP0C pin. This field and the capture function are inactive in PWM mode.
00 = Capture input CTCAP0C is ignored
01 = Rising edge of CTCAP0C
10 = Falling edge of CTCAP0C
11 = Both edges of CTCAP0C
3:2 CAPB
Input Edge Select Selects the edge used as the capture trigger on the
CTCAP0B pin. This field and the capture function are inactive in PWM mode.
00 = Capture input CTCAP0B is ignored
01 = Rising edge of CTCAP0B
10 = Falling edge of CTCAP0B
11 = Both edges of CTCAP0B
1:0 CAPA
Input Edge Select Selects the edge used as the capture trigger on the
CTCAP0A pin. This field and the capture function are inactive in PWM mode.
00 = Capture input CTCAP0A is ignored
01 = Rising edge of CTCAP0A
10 = Falling edge of CTCAP0A
11 = Both edges of CTCAP0A
Table 15-7. CMP_CAP_CTRL0 Register Definitions
