LH79524/LH79525 User’s Guide UARTs
Version 1.0 16-21
6RTIM
Receive Timeout Error Interrupt Mask When read, returns the current
mask for the RTIM interrupt. Write values:
1 = Enable the RTI interrupt
0 = Mask the RTI interrupt
5TXIM
Transmit Interrupt Mask When read, returns the current mask for the TXIM
interrupt. Write values:
1 = Enable the TXI interrupt
0 = Mask the TXI interrupt
4RXIM
Receive Interrupt Mask When read, returns the current mask for the RXIM
interrupt. Write values:
1 = Enable the RXI interrupt
0 = Mask the RXI interrupt
3:2
/// Reserved Reading returns 0. Write the reset value.
1CTS0IM
CTS0 Interrupt Mask (only for UART0) When Read, returns the current mask
for the CTS0 interrupt. Write values:
1 = Enable the CTS0 interrupt
0 = Mask the CTS0 interrupt
0
/// Reserved Reading returns 0. Write the reset value.
Table 16-27. UARTIMSC Fields (Cont’d)
BITS NAME DESCRIPTION
