LH79524/LH79525 User’s Guide UARTs

Version 1.0 16-23

5TXRIS

Transmit Interrupt Status Specifies the raw interrupt state of the

UARTTXINTR interrupt.

1 = Interrupt pending

0 = No interrupt

4RXRIS

Receive Interrupt Status Specifies the raw interrupt state of the

UARTRXINTR interrupt.

1 = Interrupt pending

0 = No interrupt

3:2 /// Reserved Do not modify.

1CTS0IS

CTS0 Interrupt Status (only for UART0) Specifies the raw interrupt state of

the UARTCTS0 interrupt.

1 = Interrupt pending

0 = No interrupt

/// Reserved Reading returns 0. Write the reset value.

Table 16-29. UARTRIS Fields

BITS NAME DESCRIPTION
