C613-50055-01 REV A Command Reference for x230 Series Edge Switches 1015
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
LOCAL RADIUS SERVER COMMANDS
EGRESS
-VLAN-ID
egress-vlan-id
Overview Use this command to configure the standard RADIUS attribute “Egress-VLANID
(56)” for the local RADIUS Server user group.
Use the no variant of this command to remove the Egress-VLANID attribute from
the local RADIUS server user group.
Syntax
egress-vlan-id <vid> [tagged|untagged]
no egress-vlan-id
Default By default, no Egress-VLANID attributes are configured.
Mode RADIUS Server Group Configuration
Usage When a Voice VLAN is configured for dynamic VLAN allocation (switchport voice
vlan command), the RADIUS server must be configured to send the VLAN
information when an IP phone is successfully authenticated. Use either the
egress-vlan-id command or the egress-vlan-name command, and specify the
tagged parameter.
Examples To set the “Egress-VLANID” attribute for the NormalUsers local RADIUS server user
group to VLAN identifier 200, with tagged frames, use the commands:
awplus# configure terminal
awplus(config)# radius-server local
awplus(config-radsrv)# group NormalUsers
awplus(config-radsrv-group)# egress-vlan-id 200 tagged
To remove the “Egress-VLANID” attribute for the NormalUsers local RADIUS server
user group, use the commands:
awplus# configure terminal
awplus(config)# radius-server local
awplus(config-radsrv)# group NormalUsers
awplus(config-radsrv-group)# no egress-vlan-id
Parameter Description
<vid> The VLAN identifier to be used for the Egress VLANID attribute, in
the range 1 to 4094.
tagged Set frames on the VLAN as tagged. This sets the tag indication field
to indicate that all frames on this VLAN are tagged.
untagged Set all frames on the VLAN as untagged. This sets the tag indication
field to indicate that all frames on this VLAN are untagged.
