C613-50055-01 REV A Command Reference for x230 Series Edge Switches 557
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
IP ADDRESSING AND PROTOCOL COMMANDS
SHOW
IP TRAFFIC
Output Figure 15-6: Example output from the show ip traffic command
IP:
261998 packets received
261998 delivered
261998 sent
69721 multicast packets received
69721 multicast packets sent
23202841 bytes received
23202841 bytes sent
7669296 multicast bytes received
7669296 multicast bytes sent
IPv6:
28 packets discarded on transmit due to no route
ICMP6:
UDP6:
UDPLite6:
TCP:
0 remote connections established
40 local connections established
7 remote listening ports
7 local listening ports
261 active connection openings
247 passive connection openings
14 connection attempts failed
122535 segments received
122535 segments transmitted
14 resets transmitted
227 TCP sockets finished time wait in fast timer
155 delayed acks sent
21187 headers predicted
736 pure ACKs
80497 pure ACKs predicted
UDP:
139468 datagrams received
139468 datagrams sent
UDPLite:
Table 15-5: Parameters in the output of the show ip traffic command
Parameter Description
IPv4 IPv4 counters
IPv6 IPv6 counters
received packets with no route Received packets with no route
truncated packets received Truncated packets received
multicast packets received Multicast packets received
multicast packets sent Multicast packets sent
broadcast packets received Broadcast packets received
broadcast packets sent Broadcast packets sent
bytes received Bytes received
bytes sent Bytes sent
