C613-50055-01 REV A Command Reference for x230 Series Edge Switches 663
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
MLD SNOOPING COMMANDS
IPV
6 MLD STATIC-GROUP
ipv6 mld static-group
Overview Use this command to statically configure IPv6 group membership entries on an
interface. To statically add only a group membership, do not specify any
parameters.
Use the no variant of this command to delete static group membership entries.
Syntax
ipv6 mld static-group <ipv6-group-address> [source
<ipv6-source-address>|ssm-map] [interface <port>]
no ipv6 mld static-group <ipv6-group-address> [source
<ipv6-source-address>|ssm-map] [interface <port>]
Mode Interface Configuration for a VLAN interface.
Usage This command applies to MLD Snooping on a VLAN interface to statically add
groups and/or source records.
Parameter Description
<ipv6-group-
address>
Specify a standard IPv6 Multicast group address to be
configured as a static group member.
The IPv6 address uses the format X:X::X:X.
<ipv6-source-
address>
Optional. Specify a standard IPv6 source address to be
configured as a static source from where multicast
packets originate.
The IPv6 address uses the format X:X::X:X.
ssm-map Mode of defining SSM mapping. SSM mapping statically
assigns sources to MLDv1 groups to translate these (*,G)
groups' memberships to (S,G) memberships for use with
PIM-SSM.
<port> Optional. Physical interface. This parameter specifies a
physical port. If this parameter is used, the static
configuration is applied to just to that physical interface.
If this parameter is not used, the static configuration is
applied on all ports in the VLAN.
