502 Command Reference for x230 Series Edge Switches C613-50055-01 REV A
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
LINK AGGREGATION COMMANDS
SHOW
STATIC-CHANNEL-GROUP
show static-channel-group
Overview Use this command to display all configured static channel groups and their
corresponding member ports. Note that a static channel group is the same as a
static aggregator.
The command output also shows the thrash limiting status. If thrash limiting is
detected and the thrash limiting parameter of the thrash-limiting command is set
to vlan disable, the output will also show the VLANs on which thrashing is
detected.
For information on filtering and saving command output, see “Controlling “show”
Command Output” in the “Getting Started with AlliedWare Plus” Feature Overview
and Configuration Guide.
Syntax
show static-channel-group
Mode User Exec and Privileged Exec
Example
awplus# show static-channel-group
Output Figure 13-8: Example output from the show static-channel-group command
Related
Commands
static-channel-group
% LAG Maximum : 128
% LAG Static Maximum: 96
% LAG Dynamic Maximum: 32
% LAG Static Count : 2
% LAG Dynamic Count : 2
% LAG Total Count : 4
% Static Aggregator: sa2
% Member:
port1.0.1
% Static Aggregator: sa3
% Member:
port1.0.2
