666 Command Reference for x230 Series Edge Switches C613-50055-01 REV A
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
MLD SNOOPING COMMANDS
SHOW
IPV6 MLD GROUPS
show ipv6 mld groups
Overview Use this command to display the multicast groups with receivers directly
connected to the router, and learned through MLD.
For information on filtering and saving command output, see “Controlling “show”
Command Output” in the “Getting Started with AlliedWare Plus” Feature Overview
and Configuration Guide.
Syntax
show ipv6 mld groups [<ipv6-address> |<interface>] [detail]
Mode User Exec and Privileged Exec
Examples The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups
Output
The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups detail
Output
Parameter Description
<ipv6-address> Optional. Specify Address of the multicast group in format
X:X::X:X.
<interface> Optional. Specify the Interface name for which to display local
information.
MLD Connected Group Membership
Group Address Interface Uptime Expires Last Reporter
ff08::1 port1.0.1 00:00:24 stopped fe80::eecd:6dff:fe6b:4783
MLD Connected Group Membership Details for port1.0.1
Interface: port1.0.1
Group: ff08::1
Uptime: 00:00:13
Group mode: Include ()
Last reporter: fe80::eecd:6dff:fe6b:4783
Group source list: (R - Remote, M - SSM Mapping, S - Static )
Source Address Uptime v2 Exp Fwd Flags
2001:db8::1 00:00:13 00:04:07 Yes R
2002:db8::3 00:00:13 00:04:07 Yes R
