766 Command Reference for x230 Series Edge Switches C613-50055-01 REV A
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
QOS COMMANDS
MATCH
ACCESS-GROUP
match access-group
Overview Use this command to define match criterion for a class-map.
Syntax
match access-group {<hw-IP-ACL>|<hw-MAC-ACL>|<hw-named-ACL>}
no match access-group
{<hw-IP-ACL>|<hw-MAC-ACL>|<hw-named-ACL>}
Mode Class Map Configuration
Usage First create an access-list that applies the appropriate permit/deny requirements.
Then use the match access-group command to apply this access-list for matching
to a class-map. Note that this command will apply the access-list matching only to
incoming data packets.
Examples To configure a class-map named cmap1 with one match criterion: access-list
3001, which allows IP traffic from any source to any destination, use the
commands:
awplus# configure terminal
awplus(config)# access-list 3001 permit ip any any
awplus(config)# class-map cmap1
awplus(config-cmap)# match access-group 3001
To configure a class-map named cmap2 with one match criterion: access-list
3001, which allows MAC traffic from any source to any destination, use the
commands:
awplus# configure terminal
awplus(config)# access-list 4001 permit any any
awplus(config)# class-map cmap2
awplus(config-cmap)# match access-group 4001
Parameter Description
<hw-IP-ACL> Specify a hardware IP ACL number in the range <3000-3699>.
<hw-MAC-ACL> Specify a hardware MAC ACL number in the range <4000-4699>.
<hw-named-ACL> Specify the hardware named ACL.
