C613-50055-01 REV A Command Reference for x230 Series Edge Switches 839
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
802.1X COMMANDS
SHOW
DOT1X STATISTICS INTERFACE
show dot1x statistics interface
Overview This command shows the authentication statistics for the specified interface,
which may be a static channel (or static aggregator) or a dynamic (or LACP)
channel group or a switch port.
For information on filtering and saving command output, see “Controlling “show”
Command Output” in the “Getting Started with AlliedWare Plus” Feature Overview
and Configuration Guide.
Syntax
show dot1x statistics interface <interface-list>
Mode Privileged Exec
Example See sample output below showing 802.1X authentication statistics for
port1.0.6:
awplus# show dot1x statistics interface port1.0.6
Parameter Description
<interface-list> The interfaces or ports to configure. An interface-list can be:
•an interface (e.g. vlan2), a switch port (e.g. port1.0.6),
a static channel group (e.g. sa2) or a dynamic (LACP)
channel group (e.g. po2)
• a continuous range of interfaces, ports, static channel
groups or dynamic (LACP) channel groups separated by a
hyphen; e.g. vlan2-8, or port1.0.1-1.0.4, or sa1-2,
or po1-2
• a comma-separated list of the above; e.g.
port1.0.1,port1.0.4-1.0.6. Do not mix interface
types in a list
The specified interfaces must exist.
802.1X statistics for interface port1.0.6
EAPOL Frames Rx: 5 - EAPOL Frames Tx: 16
EAPOL Start Frames Rx: 0 - EAPOL Logoff Frames Rx: 0
EAP Rsp/Id Frames Rx: 3 - EAP Response Frames Rx: 2
EAP Req/Id Frames Tx: 8 - EAP Request Frames Tx: 2
Invalid EAPOL Frames Rx: 0 - EAP Length Error Frames Rx: 0
EAPOL Last Frame Version Rx: 1 - EAPOL Last Frame
Src:00d0.59ab.7037
