1278 Command Reference for x230 Series Edge Switches C613-50055-01 REV A
AlliedWare Plusâ„¢ Operating System - Version 5.4.5-0.x
AMF COMMANDS
SHOW
ATMF TECH
NOTE: The show atmf tech command can produce very large output. For this reason
only the most significant terms are defined in this table.
Role The role configured on the device within the AMF - either master or member.
Current ATMF Nodes A count of the AMF nodes in the AMF network.
Node Address The identity of a node (in the format name.atmf) that enables its access it from a
remote location.
Node ID A unique identifier assigned to an AMF node.
Node Depth The number of nodes in path from this node to the core domain.
Domain State A node’s state within an AMF Domain - either controller or backup.
Recovery State The AMF node recovery status. Indicates whether a node recovery is in progress
on this device - either Auto, Manual, or None.
Management VLAN The VLAN created for traffic between nodes of different domains (up/down
links).
VLAN ID - In this example VLAN 4092 is configured as the Management VLAN.
Management Subnet - the Network prefix for the subnet.
Management IP Address - the IP address allocated for this traffic.
Management Mask - the Netmask used to create a subnet for this traffic
255.255.128.0 (= prefix /17)
Domain VLAN The VLAN assigned for traffic between Nodes of same domain (crosslink).
VLAN ID - In this example VLAN 4091 is configured as the domain VLAN.
Domain Subnet - the Subnet address used for this traffic.
Domain IP Address - the IP address allocated for this traffic.
Domain Mask - the Netmask used to create a subnet for this traffic 255.255.128.0
(= prefix /17)
Device Type Shows the Product Series Name.
ATMF Master Indicates the nodes membership of the core domain (membership is indicated
by Y)
SC Shows switch configuration:
• C - Chassis (such as SBx8100 series)
•S - Stackable (VCS)
•N - Standalone
Parent A node to which connects to the present node’s uplink, i.e. one layer higher in
the hierarchy.
Node Depth Shows the number of nodes in path from the current node to the Core domain.
Table 35-27: Parameter definitions from the show atmf tech command (cont.)
Parameter Definition
