C613-50055-01 REV A Command Reference for x230 Series Edge Switches 711
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
IPV4 SOFTWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST EXTENDED (NAMED)
<source> The source address of the packets. You can specify a single host, a
subnet, or all sources. The following are the valid formats for
specifying the source:
any Matches any source IP address.
host<ip-addr> Matches a single source host with the
IP address given by <ip-addr> in
dotted decimal notation.
<ip-addr>/
<prefix>
An IPv4 address, followed by a forward
slash, then the prefix length. This
matches any source IP address within
the specified subnet.
<ip-addr>
<reverse-mask>
Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255 is the same as entering
192.168.1.1/24.
<destination> The destination address of the packets. You can specify a single
host, a subnet, or all destinations. The following are the valid
formats for specifying the destination:
any Matches any destination IP address.
host<ip-addr> Matches a single destination host with
the IP address given by <ip-addr> in
dotted decimal notation.
<ip-addr>/
<prefix>
An IPv4 address, followed by a forward
slash, then the prefix length. This
matches any destination IP address
within the specified subnet.
<ip-addr>
<reverse-mask>
Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255 is the same as entering
192.168.1.1/24.
Table 22-2: Parameters in the access-list extended (named) command - icmp
Parameter Description
