DGS-6604 m show qos interface
CLI Reference Guide
745
The following example displays the CoS bandwidth allocation for ports eth3.1-
3.2:
This example displays the DSCP to color map for ports eth3.1 to eth3.2.
This example displays the CoS to color map for ports eth3.3 to eth3.4.
Switch> show qos interface eth3.1-3.2 bandwidth
Bandwdith Control Table
Interface Ingress Rate (Kbps) Egress Rate (Kbps)
------------------------------------------------------
eth3.1 64 (qos) 128 (qos)
eth3.2 256 (dot1x) 256 (dot1x)
Total Entries: 2
Switch> show qos interface eth3.1-3.2 map dscp-color
eth3.1
DSCP 0-7,44-63 are mapped to Green
DSCP 41-43 are mapped to Yellow
DSCP 8-40 are mapped to Red
eth3.2
DSCP 0-63 are mapped to Green
Total Entries: 2
Switch> show qos interface eth3.3-3.4 map cos-color
eth3.3
CoS 0-2,5,7 are mapped to Green
CoS 3-4 are mapped to Yellow
CoS 6 are mapped to Red
eth3.4
CoS 0-7 are mapped to Green
Total Entries: 2
