DGS-6604 m vlan remarking
CLI Reference Guide
922
vlan remarking
Use this command to define the VLAN remarking pair. Use the no form of this
command to delete the related VLAN remarking pair.
vlan remarking S-VID C-VID
no vlan remarking C-VID[, | -]
Default No VLAN remarking pair is created.
Once a VLAN remarking pair is created, the CoS setting is set to customer CoS
trusted by default.
Command Mode Interface configuration (only available for a UNI port)
Usage Guideline C-VID [, | -] is a customer VLAN list. After receiving packets of these VLANs, the
switch will replace the VLAN tag of the packets with the specified S-VID VLAN
tag. The priority tag of the outgoing tag is decided by following the following
conditions:
1.If the C-VID is set as remarking priority by the cos remarking command, the
priority tag value of the outgoing tag is decided by the configuration associated
with the ingress port and inner VID.
2.Otherwise, the priority tag value of the outer VLAN value is retained as the
original CoS priority tag value.
Example This example shows how to create VLAN translation entries. The created VLAN
translation relationships are: C-VLAN 200 will be translated to SP-VLAN 1002,
priority is 7. And the S-TAG is added.
Please follow the example below for a step by step explanation
1. Go to interface Ethernet 4.1
2. Make a VLAN encapsulation table - S-VID is 1001 and CVID is 101-104. So
far the user's COS is trusted.
Syntax Description
C-VID[, | -] The VLAN IDs specified here refers to the inner-VID list (i.e. customer VLAN ID,
C-VID).
S-VID The VLAN ID specified here refers to the outer-VIDs (i.e. service provider VLAN
ID, S-VID).
Switch(config)#>interface eth4.1
Switch(config-if)#>vlan encapsulation 1001 101-104
