Grandstream Networks UCM630X Series User Manual

P a g e | 108
UCM630X Series User Manual
Version 1.0.11.10
Configure the "Phonebook Prefix" first. The "Phonebook DN" will be automatically filled in. For example, if
configuring "Phonebook Prefix" as "people", the "Phonebook DN" will be filled with "ou=people,dc=pbx,dc=com".
Once added, users can select to edit the phonebook attributes and contact list (see figure below) or select
to delete the phonebook.
Figure 42: Edit LDAP Phonebook
• Import phonebook from your computer to LDAP server
Click on “Import Phonebook” and a dialog will prompt as shown in the figure below.
Figure 43: Import Phonebook
The file to be imported must be a CSV, VCF or XML file with UTF-8 encoding. Users can open the file with
Notepad and save it with UTF-8 encoding.

Grandstream Networks UCM630X Series Specifications

General

Brand	Grandstream Networks
Model	UCM630X Series
Category	Conference System
Language	English
