P a g e | 514

UCM630X Series User Manual

Version 1.0.11.10

Table 142: Interface Status Indicators

USB connected.

USB disconnected.

SD Card connected.

SD Card disconnected.

LAN/WAN connected.

LAN/WAN not configured.

LAN/WAN disconnected.

FXS/FXO connected.

FXS/FXO waiting.

FXS/FXO busy.

FXS/FXO not configured.

FXS/FXO disconnected.

System Status

The UCM630X system status can be accessed via Web GUI→Status→System Status, which displays the

following system information.
