UCM630X Series User Manual
Version 1.0.11.10
External TLS Port
Configures the externally mapped TLS port when UCM630X is behind a static
NAT or PAT.
Local Network
Address
Specify a list of network addresses that are considered inside of the NAT
network. Multiple entries are allowed. If not configured, the external IP address
will not be set correctly.
A sample configuration could be as follows:
192.168.0.0/16
SIP Settings/TOS
Table 114: SIP Settings/ToS
ToS for SIP
Configure the Type of Service for SIP packets. The default setting is None.
ToS for RTP Audio
Configure the Type of Service for RTP audio packets. The default setting is None.
ToS for RTP Video
Configure the Type of Service for RTP video packets. The default setting is None.
Default
Incoming/Outgoing
Registration Time
Configure the default duration (in seconds) of incoming/outgoing registration.
The default setting is 120.
Max
Registration/Subscrip
tion Time
Configure the maximum duration (in seconds) of incoming registration and
subscription allowed by the UCM630X. The default setting is 3600.
Min
Registration/Subscrip
tion Time
Configure the minimum duration (in seconds) of incoming registration and
subscription allowed by the UCM630X. The default setting is 60.
Enable Relaxed DTMF
Select to enable relaxed DTMF handling. The default setting is "No".
DTMF Mode
Select DTMF mode to send DTMF. The default setting is RFC4733. If "Info" is
selected, SIP INFO message will be used. If "Inband" is selected, a-law or u-law
are required. When "Auto" is selected, "RFC4733" will be used if offered,
otherwise "Inband" will be used. The default setting is "RFC4733".
