UCM630X Series User Manual
Version 1.0.11.10
Select a trunk for this SLA from the Available SLA Trunks list. Click on
to arrange the order. If there are multiple trunks selected, when there are
calls on those trunks at the same time, pressing the LINE key on the phone will
pick up the call on the first trunk here.
Configure the time (in seconds) to ring the station before the call is considered
unanswered. No timeout is set by default. If set to 0, there will be no timeout.
Configure the time (in seconds) for a delay before ringing the station when a call
first comes in on the shared line. No delay is set by default. If set to 0, there will
be no delay.
This option defines the competence of the hold action for one particular trunk. If
set to “open”, any station could hold a call on that trunk or resume one held
session; if set to “private”, only the station that places the trunk call on hold could
resume the session. The default setting is “open”.
Sample Configuration
1. On the UCM630X, go to Web GUI→Extension/Trunk→Analog Trunks page. Create an analog trunk or
edit the existing analog trunk. Make sure “SLA Mode” is enabled for the analog trunk. Once enabled, this
analog trunk will be only available for the SLA stations created under Web GUI→Extension/Trunk→SLA
Station page.
Figure 109: Enable SLA Mode for Analog Trunk
2. Click on “Save”. The analog trunk will be listed with trunk mode “SLA”.
