UCM630X Series User Manual
Version 1.0.11.10
Table 3: LCD Menu Options
• Critical Events
• Other Events
• Hardware: Hardware version number
• Software: Software version number
• P/N: Part number
• WAN MAC: WAN side MAC address
• LAN MAC: LAN side MAC address
• Uptime: System uptime
• WAN Mode: DHCP, Static IP, or PPPoE
• WAN IP: IP address
• WAN Subnet Mask
• LAN IP: IP address
• LAN Subnet Mask
• WAN Mode: Select WAN mode as DHCP, Static IP, or PPPoE
• Static Route Reset: Select this to reset static route settings.
• Reboot
• Factory Reset
• LCD Test Patterns
Press DOWN and OK buttons to scroll through and select different LCD
patterns to test. Once a test is done, press the OK button to return to the
previous menu.
• Fan Mode
Select Auto or On.
• LED Test Patterns
All On, All Off, and Blinking are the available options. Selecting Back in
the menu will revert the LED indicators to their actual status.
• RTC Test Patterns
Select either 2022-02-22 22:22 or 2011-01-11 11:11 to start the RTC (Real-
Time Clock) test pattern. Check the system time from either the LCD idle
