P a g e | 501

UCM630X Series User Manual

Version 1.0.11.10

Figure 285: Create New Consumer Goods

Code

Enter the Goods Code.

Name

Enter the Name of the Goods

The Minibar page displays as:

Figure 286: Mini Bar
