P a g e | 55

UCM630X Series User Manual

Version 1.0.11.10

INSTALLATION

Before deploying and configuring the UCM630X series, the device needs to be properly powered up and

connected to a network. This section describes detailed information on the installation, connection, and warranty

policy of the UCM630X series.

Equipment Packaging

Table 2: UCM630X Equipment Packaging

Main Case

Power Adaptor

Ethernet Cable

Quick Installation Guide

Connect Your UCM630X (UCM6301 as an example)

Figure 1: UCM6301 Top View

Interface status

Information

Settings

Back

Home

Navigation Keys
