Table 120: PBX Interface Settings
Select country to set the default tones for dial tone, busy tone, ring tone and
etc. to be sent from the FXS port. The default setting is "United States of
America (USA)".
Select country to set the On-Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RING voltage adjustment, Minimum
Operational Loop Current, and AC Impedance as predefined for your country's
analog line characteristics. The default setting is "United States of America
(USA)".
Select country to set the On-Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RING voltage adjustment, Minimum
Operational Loop Current, and AC Impedance as predefined for your country's
analog line characteristics. The default setting is "United States of America
(USA)".
Configure to enable or disable override Two-Wire Impedance Synthesis
(TISS). The default setting is No.
If enabled, users can select the impedance value for Two-Wire Impedance
Synthesis (TISS) override. The default setting is 600Ω.
Select the codec to be used for analog lines. North American users should
choose PCMU. All other countries, unless already known, should be assumed
to be PCMA. The default setting is PCMU.
Note:
This option requires system reboot to take effect.
Configure whether normal ringing voltage (40V) or maximum ringing voltage
(89V) for analog phones attached to the FXS port is required. The default
setting is "Normal".
Configure to increase the ringing speed to 25HZ. This option can be used with
"Low Power" option. The default setting is "Normal".
