P a g e | 502

UCM630X Series User Manual

Version 1.0.11.10

WAKEUP SERVICE

The Wake Up service can be used to schedule a reminder or wake up calls to any valid destination. This service

is available on the UCM630X as a separated module.

There are three ways to set up Wakeup Service:

• Using admin login

• Using user portal

• Using feature code

Wake Up Service using Admin Login

1. Login to the UCM as admin.

2. Wake Up service can be found under Web GUI→Value-added Features→Wakeup Service, click

on ”Add” to create a new wakeup service. The following window will pop up.

Figure 287: Create New Wakeup Service
