P a g e | 133

UCM630X Series User Manual

Version 1.0.11.10

To start the auto-provisioning process, under Web GUI→Value-added Features→Zero Config→Zero Config

Settings, fill in the auto provision information.

Figure 63: Auto Provision Settings

Table 28: Auto Provision Settings

Enable Zero Config

Enable or disable the zero-config feature on the PBX. The default setting

is enabled.

Enable Automatic

Configuration Assignment

By default, this is disabled. If disabled, when the SIP device boots up, the

UCM630X will not send the SIP device the URL to download the config

file, and therefore the SIP device will not be automatically provisioned by

the UCM630X.

Note: When disabled, SIP devices can still be provisioned by manually

sending NOTIFY from the UCM630X which will include the XML config file

URL for the SIP device to download.
