P a g e | 570

UCM630X Series User Manual

Version 1.0.11.10

Figure 355: Local Backup

Data Sync

Besides local backup, users could backup the voice records/voice mails/CDR in a daily basis to a remote server

via SFTP protocol automatically under Web GUI→Maintenance→Backup→Data Sync.

The client account supports special characters such as @ or “.” Allowing the use email address as SFTP

accounts. It allows users as well to specify the destination directory on SFTP server for backup file. If the directory

does not exist on the destination, UCM630X will create the directory automatically
