Display Email Notification status for the extension.

When notification is waiting for be sent, shows and once sent it will display

Terminal Type

Displays extension type.

• SIP User

• IAX User

• Analog User

• Ring Groups

• Voicemail Groups

Interfaces Status

This section displays interface/port connection status on the UCM630X. The following example shows the

interface status for UCM6304 with USB, WAN port, FXS1, FXS2 and FXO1 connected.

Figure 296: UCM6304 Interfaces Status
