Grandstream Networks UCM630X Series User Manual

P a g e | 273
UCM630X Series User Manual
Version 1.0.11.10
Scheduled Sync
The UCM630X allows users to synchronize the outbound routes, this feature can be found on the Web
GUI→Extension/Trunk→Outbound Routes→ Scheduled Sync.
Table 68: Outbound Routes/Scheduled Sync
Scheduled Sync
Enable the Scheduled Sync feature
Server Address
Enter the TFTP server address. For example, "192.168.1.2:69".
File Name
Specify the file name
Sync Time
Enter the sync time (24hr format). The valid range is 0-23.
Sync Frequency
Create new sync every x day(s). The valid range is 1 to 30.
PIN Groups
The UCM630X supports the pin group. Once this feature is configured, users can apply pin groups to specific
outbound routes. When placing a call on pin-protected outbound routes, the caller will be asked to input the
group pin number, this feature can be found on the Web GUI→Extension/Trunk→Outbound Routes→PIN
Groups.
Table 69: Outbound Routes/PIN Group
Name
Specify the name of the group
Record In CDR
Specify whether to enable/disable record in CDR
PIN Number
Specify the code that will be asked once dialing via a trunk
PIN Name
Specify the name of the PIN
Once the user clicks , the following figure shows to configure the new PIN.
