P a g e | 92

UCM630X Series User Manual

Version 1.0.11.10

• dydns.org

• noip.com

• freedns.afraid.org

• zoneedit.com

• oray.net

Here is an example of using noip.com for DDNS.

1. Register domain in DDNS service provider. Please note the UCM630X needs to have public IP access.

Figure 30: Register Domain Name on noip.com

2. On Web GUI→System Settings→Network Settings→DDNS Settings, enable DDNS service and

configure username, password, and host name.
