P a g e | 339

UCM630X Series User Manual

Version 1.0.11.10

Figure 170: Voicemail Group

Table 80: Voicemail Group Settings

Extension

Enter the Voicemail Group Extension. The voicemail messages left to this extension

will be forwarded to all the voicemail group members.

Name

Configure the Name to identify the voicemail group. Letters, digits, _ and - are

allowed.

Voicemail

Password

Configure the voicemail password for the users to check voicemail messages.

Email Address

Configure the Email address for the voicemail group extension.

Member

Select available mailboxes from the left list and add them to the right list. The

extensions need to have voicemail enabled to be listed in available mailboxes list.

Busy Prompt

Voicemail prompt will be played when user enters voicemail. Priority: Temporary

Prompt > Busy Prompt/Unavailable Prompt > Greet Prompt
