P a g e | 520

UCM630X Series User Manual

Version 1.0.11.10

Figure 300: Alert Event List

Table 145: Alert Events

Action index

Alert Events

Fail2ban Blocking

User Login Banned

System Crash

Restore Config

System Update

System Reboot

TLS Cert Expiration

HA failure warning

Cloud IM abnormal

Modify Super Admin Password

NAS

Disk Usage

Default Chapter4
