BUSY CAMP-ON

The UCM630X supports busy camp-on/call completion feature that allows the PBX to camp on a called party

and inform the caller as soon as the called party becomes available given the previous attempted call has failed.

The configuration and instructions on how to use busy camp-on/call completion feature can be found in the

following guide:

https://www.grandstream.com/sites/default/files/Resources/ucm6xxx_busy_camp_on_guide.pdf
