Grandstream Networks UCM630X Series User Manual

P a g e | 147
UCM630X Series User Manual
Version 1.0.11.10
Layer 2 QoS Priority Value
Assign the priority value of the Layer 2 QoS packets.
The valid range is 0-7.
STUN Server
Configure the IP address or Domain name of the STUN server. Only non-
symmetric NAT routers work with STUN.
Keep-Alive
Select either to enable or disable Keep Alive.
Keep Alive Interval
Specify how often the phone will send a blank UDP packet to the SIP server
to keep the “ping hole” on the NAT router open. The valid range is 10-160.
Register Expiration
Specify the Register Expiration.
Local SIP Port
Configure Local SIP Port.
Local RTP Port
Configure Local RTP Port.
Auto On-Hook Timer(s)
Configure Auto On-Hook Timer(s).
Ring Timeout
Configure Ring Timeout.
SIP Transport
Select either UDP, TCP, or TLS/TCP as SIP transport protocol.
Direct IP Call
Select either to disable or enable Direct IP Call support.
SIP Proxy Compatibility
Mode
Select either to disable or enable SIP Proxy Compatibility Mode.
Unregister On Reboot
Select either to disable or enable Unregister On Reboot.
Whitelist
Whitelist
Select either to enable or disable Whitelist
SIP Phone Number Whitelist
Configure the SIP Phone Number Whitelist.
Table 34: Global Policy Parameters – Customization
Wallpaper
Screen Resolution 1024 x
600
Check this option if the SIP end device shall use 1024 x 600 resolution for
the LCD screen wallpaper.
