P a g e | 516

UCM630X Series User Manual

Version 1.0.11.10

IPv4 Address

IPv4 address.

IPv6 Address Link

IPv6 address

Gateway

Default gateway address.

Subnet Mask

Subnet mask address.

DNS Server

DNS Server address.

Duplex Mode

Speed

Remark

The UCM admin could add remark on UCM web UI->System Status->System Information->Remark to log any

necessary information for the UCM such as location, technical contacts, important topology information and etc.

This could be useful for UCM admin especially when there are multiple UCMs to be managed.

If this UCM has UCMRC service, the remark will also be sync up to GDMS. If this information is edited on GDMS,

it will also be updated to the UCM web UI.

Figure 297: System Status→System Information->Remark
