Create New Device
Besides configuring the device after the device is discovered, users could also directly create a new device and
configure basic settings before the device is discovered by the UCM630X. Once the device is plugged in, it can
then be discovered and provisioned. This gives the system administrator adequate time to set up each device
beforehand.
Click on "Add" and the following dialog will show. Follow the steps below to create the configurations for the new
device.
1. Firstly, select a model for the device to be created and enter its MAC address, IP address, and firmware
version (optional) in the corresponding field.
2. Basic settings will show a list of settings based on the model selected in step 1. Users could assign
extensions to accounts, assign functions to Line Keys and Multiple-Purposed Keys if supported on the
selected model.
3. Click on “save” to save the configuration for this device.
Figure 74: Create New Device
