P a g e | 117

UCM630X Series User Manual

Version 1.0.11.10

Figure 52: Create New Holiday

Table 23: Create New Holiday

Name

Specify the holiday name to identify this holiday.

Holiday Memo

Create a note for the holiday.

Month

Select the month for the holiday.

Year

Select the Year for the holiday.

Note: In the "Year" option, select "All" to set annual fixed holiday

information.

Day

Select the day for the holiday.

Show Advanced Options

Check this option to show advanced options. If selected, please specify

the days as holiday in one week below.

Week

Select the days as holiday in one week.
