Protocol
Protocol used to communicate with the server. HTTP or HTTPS.
Default one is HTTP.
HTTP Server
The IP address or FQDN of the HTTP/HTTPS server.
HTTP Server Port
HTTP/HTTPS port
Warning Template
Customize the template used for system warnings.
By default: {"action":"${ACTION}","mac":"${MAC}","content":"${WARNING_MSG}"}
Notification
Template
Customize the notification template to receive relevant alert information.
By default:
{"action":"${ACTION}","cpu":"${CPU_USED}","memery":"${MEM_USED}","disk":"${
DISK_USED}","external_disk":"${EXTERNAL_DISK_USED}"}
Note: The notification message with “action:0” will be sent periodically if Notification
Interval is set.
Notification
Interval
Modifies the frequency at which notifications are sent in seconds.
No notifications will be sent if the value is "0". Default value: 20
Template
Variables
${MAC} : MAC Address
${WARNING_MSG} : Warning message
${TIME} : Current System Time
${CPU_USED} : CPU Usage
${MEM_USED} : Memory Usage
${ACTION} : Message Type. Refer to [Table 145: Alert Events]
${DISK_USED} : Disk Usage
${EXTERNAL_DISK_USED} : Disk Usage
CDR
CDR (Call Detail Record) is a data record generated by the PBX that contains attributes specific to a single
instance of phone call handled by the PBX. It has several data fields to provide detailed description for the call,
