UCM630X Series User Manual
Version 1.0.11.10
Table 11: UCM630X Network Settings→Static Routes
Destination
Configure the destination IPv4 address or the destination IPv6 subnet for the
UCM630X to reach using the static route.
Example:
IPv4 address - 192.168.66.4
IPv6 subnet - 2001:740:D::1/64
Subnet Mask
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
Gateway
Configure the IPv4 or IPv6 gateway address so that the UCM630X can reach the
destination via this gateway. The gateway address is optional.
Example:
192.168.40.5 or 2001:740:D::1
Interface
Specify the network interface on the UCM630X to reach the destination using the
static route.
LAN interface is eth0; WAN interface is eth1.
Static routes configuration can be reset from the LCD menu→Network Menu.
The following diagram shows a sample application of static route usage on UCM6304.
