P a g e | 450

UCM630X Series User Manual

Version 1.0.11.10

Send Compact SIP

Headers

If enabled, compact SIP headers will be sent. The default setting is "No".

Passthrough PAI

Header

Passthrough PAI Header

SIP Settings/STIR/SHAKEN

To prevent robocalls, UCM now supports STIR/SHAKE protocols. Related options have been added as a new

tab in the SIP Settings page.

Clicking on the Add button will show the following window:

Figure 244:SIP Settings/STIR/SHAKEN - Add Authentication Number
