Configure Announcement Paging

Figure 180: Announcement Paging

Table 85: Announcement Paging Configuration Parameters

Enable

Enable/Disable Announcement Paging.

Name

Configure paging/intercom group name.

Type

Select "Announcement Paging”

Custom Prompt

This option is to set a custom prompt for a paging/intercom group to announce

to caller. Click on ‘Prompt’, it will direct the users to upload the customized voice

prompts.

Note: Users can also refer to the page PBX Settings→Voice Prompt→Custom
