UCM630X Series User Manual
Version 1.0.11.10
• Manual
Once selected, users need to specify downloading protocol HTTP,
HTTPS, or TFTP and the server path to download the phonebook XML
file. The server path could be an IP address or URL, with up to 256
characters.
• Local UCM Server
Once selected, click on the Server Path field to upload the phonebook
XML file. Please note after uploading the phonebook XML file to the
server, the original file name will be used as the directory name and
the file will be renamed as phonebook.xml under that directory.
Phonebook Download
Interval
Configure the phonebook download interval (in minutes). If set to 0, the
automatic download will be disabled. The valid range is 5 to 720.
Remove manually edited
entries on download
If set to “Yes”, when XML phonebook is downloaded, the entries added
manually will be automatically removed.
Table 32: Global Policy Parameters – Maintenance
Firmware source via ZeroConfig provisioning could be a URL for external
server address, local UCM directory, or USB media if plugged into the
UCM630X. Select a source to get the firmware file:
• URL
If selected to use URL to upgrade, complete the configuration for the
following four parameters: “Upgrade Via”, “Server Path”, “File Prefix”
and “File Postfix”.
• Local UCM Server
Firmware can be uploaded to the UCM630X internal storage for
firmware upgrade. If selected, click on the “Manage Storage” icon next
to the “Directory” option, upload the firmware file, and select a directory
for the end device to retrieve the firmware file.
