such as phone number of the calling party, phone number of the receiving party, start time, call duration, etc.
On the UCM630X, the CDR can be accessed under Web GUI→CDR→CDR. Users could filter the call report by
specifying the date range and criteria, depending on how the users would like to include the logs to the report.
Click on "Filter" button to display the generated report.
Figure 309: CDR Filter
Table 147: CDR Filter Criteria
Call Type
Groups the following:
• Inbound calls: Inbound calls are calls originated from a non-internal source
(like a VoIP trunk) and sent to an internal extension.
• Outbound calls: Outbound calls are calls sent to a non-internal source (like
a VoIP trunk) from an internal extension.
• Internal calls: Internal calls are calls from one internal extension to another
extension, which are not sent over a trunk.
• External calls: External calls are calls sent from one trunk to another trunk,
which are not sent to any internal extension.
Status
Filter with the call status, the available statuses are the following:
• Answered
• No Answer
