P a g e | 530

UCM630X Series User Manual

Version 1.0.11.10

• Busy

• Failed

Source Trunk

Name

Select source trunk(s) and the CDR of calls going through inbound the trunk(s) will be

filtered out.

Destination Trunk

Name

Select destination trunk(s) and the CDR of calls going outbound through the trunk(s)

will be filtered out.

Action Type

Filter calls using the Action Type, the following actions are available:

• Announce

• Announcement page

• Dial

• Announcements

• Callback

• Call Forward

• Conference

• DISA

• Follow Me

• IVR

• Page

• Parked Call

• Queue

• Ring Group

• Transfer

• VM

• VMG

• Video Conference
