P a g e | 531

UCM630X Series User Manual

Version 1.0.11.10

• VQ_Callback

• Wakeup

• Emergency Call

• Emergency Notify

• SCA

Extension Group

Specify the Extension Group name to filter with.

Export File Data

Select the fields that will be exported, the following fields are available:

• Account Code

• Session

• Premier caller

• Action type

• Source trunk name

• Destination trunk name

• Caller number

• Caller ID

• Caller name

• Callee number

• Answer by

• Context

• Start time

• Answer time

• End time

• Call time

• Talk time
