P a g e | 404

UCM630X Series User Manual

Version 1.0.11.10

Local Extensions

Select the available extensions/Extension Groups listed on the local UCM630X

to be monitored in the event list.

Remote Extensions

If LDAP sync is enabled between the UCM630X and the peer UCM630X, the

remote extensions will be listed under "Available Extensions". If not, manually

enter the remote extensions under "Special Extensions" field.

Special Extensions

Manually enter the remote extensions in the peer/register trunk to be monitored

in the event list. Valid format: 5000,5001,9000

Figure 214: Create New Event List
