P a g e | 584

UCM630X Series User Manual

Version 1.0.11.10

Figure 364: Ethernet Capture

Table 157: Ethernet Capture

Capture Type

Ethernet Capture: Gets a packet capture of all network traffic

going through the device.

WebSocket Capture: Gets a packet capture of WebSocket

protocol. Mainly used for troubleshooting Wave Web calling and

conferencing issues.

Interface Type

Select the network interface to monitor.
