SLA STATION
The UCM630X supports SLA that allows mapping the key with LED on a multi-line phone to different external
lines. When there is an incoming call and the phone starts to ring, the LED on the key will flash in red and the
call can be picked up by pressing this key. This allows users to know if the line is occupied or not. The SLA
function on the UCM630X is like BLF but SLA is used to monitor external lines i.e., analog trunk on the UCM630X.
Users could configure the phone with BLF mode on the MPK to monitor the analog trunk status or press the line
key pick-up call from the analog trunk on the UCM630X.
Create/Edit SLA Station
SLA Station can be configured on Web GUI→Extension/Trunk→SLA Station.
Figure 108: SLA Station
• Click on to add an SLA Station.
• Click on to edit the SLA Station. The following table shows the SLA Station configuration parameters.
• Click on to delete the SLA Station.
Table 66: SLA Station Configuration Parameters
To Next Page
