Keep Last X Days

Automatically delete all recordings older than this x days when the threshold

is reached. If not set, all data is cleared

Cleaner Log

Press Clean “button” to clean the cleaner’s log.

All the cleaner logs will be listed on the bottom of the page.

USB/SD Card Files Cleanup

Users could configure to clean or download the Call Detail Report/Voice Records/Voice Mails automatically under

Web GUI→Maintenance→System Cleanup/Reset→USB / SD Card Files Cleanup.

Figure 361: USB/SD Card Files Cleanup

Table 156: USB/SD Card Files Cleanup

Current Path

Displays the current path.

Directory

Select the directory user want to clean.

Delete Selected File

Select multiple entries to delete from USB or SD card.
