P a g e | 354

UCM630X Series User Manual

Version 1.0.11.10

LaggedTime(seconds)

Set the delay paging duration, the default is 5 seconds.

Replace Display Name

If enabled, the UCM will replace the caller display name with Paging/Intercom

name.

Maximum Call Duration

Specify the maximum call duration in seconds. The default value 0 means no

limit.

Custom Prompt

This option is to set a custom prompt for a paging/intercom group to announce

to caller. Click on ‘Prompt’, it will direct the users to upload the customized voice

prompts.

Note: Users can also refer to the page PBX Settings→Voice Prompt→Custom

Prompt, where they could record new prompt or upload prompt files.

Members

Select available users from the left side to the paging/intercom group member

list on the right.

Paging/Intercom

Whitelist

Select which extensions are allowed to use the paging/intercom feature for this

paging group.
